Pendulum Concrete Vibrator
HOME > 제품소개 > Pendulum Concrete Vibrator / VMP Series
title of Vibromaster Inverter DSC Series

Model / VMP Series


Vibroamster의 Pendulum type의 바이브레이터는 RPM 3,000 / 3,300으로 여러분께 익숙한 일반적인 Concrete
Pendulum Concrete Vibrator Series VI-2008 / 3-Phase Motor+Inverter
vmp series
Motor / VMP Series
MODEL VMP-1075
Voltage 220V Power 0.75KW
Current 7A Pole 3-Phase(+Inverter)
Temperature 40℃

R.P.M

3450
Cycle

60Hz

Bearing

6203zz / 6204zz

Poker Heads
Model VIB.HEAD DIA LENGTH FLEXIBLE SHAFT DIA FLEXIBLE HOSE LENGTH AMPLITUDE V.P.M
VMP-28A 28.5×445mm 8.0mm 4.5×6mm 1.4mm 9,000
~
12,000
VMP-32A 32×445mm

8.0mm

4.5×6mm 1.8mm
VMP-38A

38×445mm

10mm

4.5×6mm

1.8mm
VMP-45A 45×445mm 10mm 4.5×6mm 2.0mm
VMP-50A 50×445mm 10mm 4.5×6mm 2.2mm
VMP-60A 60×445mm 13mm 4.5×6mm 2.4mm
